The most popular compact and lightweight version.
The load profile is optimized for LiFePO4 batteries
Fast charging from AC in only 5,5 hours.
It can also be used as an uninterruptible power supply for systems with AC H24
| Code | TOW-L180C-kit |
| Main power supply | AC100-240 / Lighting cycle |
| Outdoor cabinet | Fiberglass IP68 (ventilation system IP54)) |
| Lithium battery LiFePo4 | 1728Wh |
| Battery voltage | 28V |
| Full recharge | Fast Charge 10,7A/310Wh 5,5h |
| Maximum load | - |
| Charging algorithm | - |
| Photovoltaic Max Power | - |
| Rated Voltage Photovoltaics | - |
| Panel connectors MC4 | - |
| Battery cycles (DOD 80%)) | 2000 |
| Connectors IP68 RJ45 | 4 |
| Integrated display | Programmable + instantaneous volt control |
| Magnetothermic Overvoltage Arrester | Yes |
| Surge arrester | SPD tipo2 (20kA) |
| Battery protection fuse | 32A super fast |
| Door opening alarm | Yes |
| Door lock | Yes |
| Network presence check | Yes |
| Low battery contact | Yes |
| Internal temperature control | Yes |
| automatic ventilation | Yes |
| Dimensions (H. x An. x Pr.) | 500 x 430 x 210 |
| Box Weight Kg (with Mounting Kit) | 23,8 (27,9) |
| External environmental sensors | PM Integrated 1-2.5-4-10, Temperature, Humidity, Pressure |
| GSM Cloud Modem M2M | Integrated with prepaid and rechargeable SIM from 500MB |
| IoT remote control and alarms | Cloud-based data management software included |
| Support for pole installation | Included (for diameters from 50 to 140 mm) |
| Large box version 434 x 504 x 210 | - |
| Street floor box version | L180C T |
