The most popular compact and lightweight version.
The load profile is optimized for LiFePO4 batteries
Fast charging from AC in only 4 hours.
It can also be used as an uninterruptible power supply for systems with AC H24
| Code | TOW-L75C |
| Main power supply | AC100-240 / Lighting cycle |
| Outdoor cabinet | Fiberglass IP68 (ventilation system IP54)) |
| Lithium battery LiFePo4 | 864 Wh |
| Battery voltage | 14V |
| Full recharge | Fast Charge 15A/ 220Wh 4h |
| Maximum load | - |
| Charging algorithm | - |
| Photovoltaic Max Power | - |
| Rated Voltage Photovoltaics | - |
| Panel connectors MC4 | - |
| Battery cycles (DOD 80%)) | 2000 |
| Connectors IP68 RJ45 | 4 |
| Integrated display | Programmable + instantaneous volt control |
| Magnetothermic Overvoltage Arrester | Yes |
| Surge arrester | SPD tipo2 (20kA) |
| Battery protection fuse | 20A extra-fast |
| Door opening alarm | Yes |
| Door lock | Yes |
| Network presence check | Yes |
| Low battery contact | Yes |
| Internal temperature control | Yes |
| automatic ventilation | Yes |
| Dimensions (H. x An. x Pr.) | 425 x 325 x 180 |
| Box Weight Kg (with Mounting Kit) | 15,5 (19,0) |
| External environmental sensors | PM Integrated 1-2.5-4-10, Temperature, Humidity, Pressure |
| GSM Cloud Modem M2M | Integrated with prepaid and rechargeable SIM from 500MB |
| IoT remote control and alarms | Cloud-based data management software included |
| Support for pole installation | Included (for diameters from 50 to 140 mm) |
| Large box version 434 x 504 x 210 | L75C XL |
| Street floor box version | L75C T |
