| Code | TOW-SB5-POE |
| Interface | 5 RJ45 ports of 10/100/1000 Mbps (Auto Negotiation/Automatic MDI/MDIX) 1 x 1000 SFP slots of [%VAR%] Mbps 1 x console port 1 alarm input. 1 alarm output. 1 temperature sensor port. |
| Network media | 10BASE-T: uTP cable category 3, 4, 5 (maximum 100 m) 100BASE-TX/1000Base-T: uTP cable category 5, 5e, 6 or higher (max. 100 m) 1000BASE-X: MMF, SMF 1000Base-L X: 62,5 μm/50 μm MM (2 m ~ 550 m) or 10 μm SMF (2 m ~ 5000 m) |
| Fan | Without fan |
| Surge immunity | 8KV Per: IEC61000-4-5 |
| ESD protection | ESD Level 4 According to: IEC61000-4-2 RS Level 4 According to: IEC61000-4-3 EFT Level 4 according to: IEC61000-4-4 CS Level 4 according to: IEC61000-4-6 |
| External power supply | CC 37-57 V 8 A max. for PoE POE IN 802.3bt type 3/tipo 4 |
| PoE Ports (RJ45) | Standard P1- P2 : Compatible with 24 V and 802.3af/at; passive PoE Standard P3-P4: compatible with 802.3af/at/bt |
| Power Budget (max) | 225W |
| Exchange capacity | 12G |
| Packet forwarding rate | 18 Mpps |
| Mac address chart | 4K |
| Buffer memory | 8.7 Mb |
| Jumbo Frame | 10240 Bytes |
| Dimensions (length x width x height) | 145mm× 125mm× 40mm |
| Software functions | ------------------------------------------------------------------------ |
| Quality service | Supports 802.1p CoS/DSCP priority Supports 4 priority queues Queue scheduling: SP, WRR, SP+WRR Port/flow-based rate limiting |
| Characteristics of L2 | IGMP Snooping V1/V2/V3 802.3ad LACP (up to 8 aggregation groups, containing 8 ports per group) Spanning Tree STP/RSTP/MSTP Port Isolation BPDU filtering/Guard TC/Root protect Loop back detection 802.3x Flow control |
| VLAN | Supports up to 4K VLANs simultaneously (from 4K VLAN ID) Port/MAC/protocol-based VLAN Management VLAN Configuration |
| Access control list | L2-L4 Package filtering based on source and destination MAC address, IP address, TCP/UDP ports, 802.1p, DSCP, protocol and VLAN ID; Time range based |
| Security | IP-MAC-Port-VID IEEE 802.1X Port/MAC based Authentication, Radius, Guest VLAN DoS defense Dynamic ARP Inspection (DAI) SSH v1/v2 SSL v2/v3/TLSv1 Port security Broadcast/multicast/unknown broadcast storm control |
| Administration | Web-based GUI and CLI management SNMP v1/v2c/v3, compatible with public MIBs DHCP/BOOTP client, DHCP Snooping, DHCP Option82 CPU monitoring port mirroring time Configuration: SNTP Integrated NDP/NTDP function Firmware update: TFTP and web system Diagnose: VCT SYSLOG and public MIBS |
| Certification | CE, FCC, RoHS |
| ENVIRONMENT | Working temperature: -40 +80C Storage temperature: -40 +90C Operating humidity: 10% - 90 % RH non-condensing Storage humidity: 5 %-95 %RH without condensation |
| DIN | Included |
