| Brand | X-Security |
| Image sensor | 1/3" 4MP progressive CMOS |
| Maximum resolution | 4 Megapixel (2688x1520) |
| Minimum illumination | 0,01 lux to F1,6 (color, 30 IRE) |
| Lens | 2,8 mm: height: 102°; V: 54°; D: 121° |
| Bitrate | H.265: 32 kbps–6144 kbps H.264: 32 kbps–6144 kbps |
| Main Stream rate | 4M (2688 × 1520); 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1,3 M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Compression | H.265 / H264 |
| Image improvements | WDR (120dB), BLC, 3D-DNR, MD, ROI |
| Alarm Events | Motion detection; video manipulation; audio detection; security exception; PIR alarm; low-battery alarm; light alarm; alarm sound |
| Day / Night | Removable mechanical ICR filter |
| Internal memory | MicroSD card, Max 256 GB |
| Network interface | Ethernet 10M / 100M 4G Micro SIM card (LTE-TDD/LTE-FDD/WCDMA/GSM) |
| Audio | Built-in microphone |
| Remote access | WEB, CMS (DSS/PSS), Smartphone and NVR interface |
| Interoperability | ONVIF |
| Consumption | Sleep mode: 0,03 W General mode: 2,1 W Max. (4G pulling current+IR+speaker+warning light): 4 W |
| Battery | Lithium 10Ah | Battery voltage ( 3.0 V - 4.2 V) |
| Degree of protection | IP67 |
| Material | metal + plastic |
| Temp. operation | –20 °C to +60 °C (–4 °F to +140 °F) |
| Base dimensions | 238 mm × 181 mm × 296 mm (9,37" × 7,13" × 11,65") |
| Weight | 1250 g |
