Thermal Camera | |
| Brand | Hikvision |
| Thermal sensor | 160x120 Vanadium Oxide |
| Optical sensor | 1/2.7” Progressive Scan CMOS 4 Megapixel |
| Minimum illumination (for optical part) | Colour: 0.0018 Lux @ (F1.6, AGC ON), IR up to 15 m distance |
| Main Stream rate | 160x120(25fps) Thermal / 1920x1080 (25fps) Optical |
| Extra Stream rate | 160x120 (50fps) Thermal / 704x576 (25fps) Optical |
| Compression | H.265 / H.264+ / H.264 / MJPEG |
| Lens | 3 mm (Therm) / 4 mm (Opt) |
| Viewing angle | 50°×37.2° (Term) / 84°×44.8° (Opt) |
| Thermal sensitivity | < 35mK (0.05 º C) |
| Thermal measurement range | 30 ~ 45ºC / High precision ± 0.5ºC |
| Spectral range | 8~14μm |
| Pitch detector | 17μm |
| VCA ranges | 3 temperature measurement rules, up to 21 rules in total (10 points, 10 areas and 1 line) |
| Intelligent functions | Body temperature measurement |
| Features in Measurement | Up to 30 face detections in the same scene / Between 3 ~ 7 m of distance in the detection |
| Installation height | Already installed |
| Audio | 1 input / 1 line level output 600 ohm |
| Alarm | 1 Input between 0V and 5V / 1 Output NO |
| Internal memory | Micro SD card up to 256GB |
| Network interface | Ethernet 10/100 BaseT |
| Remote access | WEB, CMS (DSS/PSS), Smartphone and NVR interface |
| Interoperability | ONVIF |
| Power | Connected to metal detector |
| Temp. operation | 5º C ~ +50º C |
| Degree of protection | IP65 |
| Dimensions | 138 mm (Fo) x 138 (An) x 123 (Al) mm |
| Weight | 800 g |
Metal Detection | |
| Detection accuracy | 150 grams |
| Detection by Areas | Up to 18 areas |
| Sensitivity | 255 levels |
| Frequencies | 100 configurable |
| Indicators | LCD display and LED indicators identifying where metal objects might be |
| Power | 110 ~ 240V AC / 72W |
| Temp. operation | -20º C ~ +85º C |
| Degree of protection | IP53 |
| Dimensions | 4801 mm (Fo) x 850 (An) x 2200 (Al) mm |
| Weight | 50 Kg |
