HD1TB | |
| Capacity | 1TB |
| Interface | SATA |
| Transfer Rate | 6 Gb/s |
| Model | WD10PURX |
| Manufacturer | Western Digital |
| Buffer size | 64 MB |
| Temp. operation | 0º C ~ +65º C |
SF-NVR6108A-A1 | |
| Brand | Safire Smart |
| Range | A1 |
| Inputs for IP cameras | 8CH IP |
| IP compatible cameras | Safire Smart (native protocol), ONVIF |
| Bidirectional audio | 1 input / 1 RCA output |
| Video outputs | 1 HDMI 4K, 1 VGA |
| Main Stream recording | 8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/ 960H/D1/CIF |
| Decoding capacity | 1CH 8Mpx 4CH 1080P |
| Video compression format | H.265+ / H.265 / H.264+ / H.264 |
| Audio Compression | G.711(U/A) |
| Total bandwidth | 80 Mbps downstream / 80 Mbps upstream |
| Display resolution | HDMI: 3840x2160@60FPS/30FPS, 2560x1440, 1920x1080, 1280x1024, 1280x720, 1024x768 VGA: 1920x1080, 1280x1024, 1024x768 |
| Alarms | 8 Inputs / 4 Outputs |
| POS Function | Yes |
| Intelligent functions | Facial recognition up to 8CH Computing of up to 180 images / minute 32 Libraries and up to 5000 face images Image searches via recorder, APP and software Face tracking on map or plan Statistical information on face results. TrueSense intelligent event searches by human and vehicle (camera with TrueSense required) |
| Recording method | Manual, programmed, motion detection, smart events, alarm input, POS |
| Yesmultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| External Backup | USB memory stick / USB HDD / USB CD-RW / USB DVR-RW / |
| Internal memory | 1x 3.5" HDD SATA3.0 up to 8 TB (not included) |
| Communication | 1 x USB 3.0 / 1 x USB 2.0 / 1 x RJ45 10/100/1000M (Ethernet) / RS485 |
| Remote access | Web Browser, Safire Smartphone App and PC Software Safire Smart VMS |
| Power | DC 12V / 2A, < 10W (Without hard disk) |
| Operating temperature | -10ºC ~50ºC, Humidity 10~90% |
| Dimensions / Weight | 45(H) x 300(W) x 249(D)mm / 1Kg |
SF-IPB585ZA-4I1 | |
| Brand | Safire Smart |
| Range | I1 |
| Image sensor | 1/3" Progressive Scan CMOS |
| Maximum resolution | 4 Megapixel (2592x1520) |
| Minimum illumination | Colour: 0.005 Lux @(F1.6, AGC ON), 0 Lux with IR |
| IR range | 70 m |
| Day/Night | Removable mechanical ICR filter |
| Electronic Shutter | 1/2~1/100.000 s |
| Main Stream rate | 25 FPS (4Mpx, 2K, 3Mpx, 1080P, 720P) HFR mode: 60 FPS (1080P / 720P) |
| Extra Stream rate | 25 FPS (720P, D1, CIF, 480x240) |
| Third Stream Rate | 25 FPS (D1, 480x240, CIF) |
| Compression | H.265+ / H.265 / H.264+ / H.264 |
| Bitrate | 64 Kbps ~ 8 Mbps |
| Lens | Motorized 2.8 ~ 12 mm |
| Viewing Angle (FOV) | H: 100-28.9°, V: 54.4-16.7°, D: 104.8-33.1° |
| Range performance | W: 59 m (D), 24 m (O), 12 m (R), 6 m (I) T: 206 m (D), 82 m (O), 41 m (R), 21 m (I) |
| Image improvements | WDR, BLC, HLC, 3D-DNR, AWB, ROI, Mirror Function, Privacy Mask, ROI |
| Motion Detection | Si |
| Smart Features | Advanced artificial intelligence based on human, vehicle, and non-motorized vehicle classification on: Area Intrusion, Line Crossing, Entry Region, Exit Region Face Detection and Face Capture Counting of people, vehicles and non-motorized vehicles Feature extraction: - Human: Up to 13 characteristics - Vehicle: Up to 5 characteristics - Non-motorized vehicle: Up to 1 characteristics Other smart events: dropped object, removed object, Video exceptions (change of scene, video loss, ...) |
| Audio | 1 Input |
| Audio Compression | G711A / U |
| Alarms | 1 Input / 1 Relay |
| Network interface | Ethernet 10 / 100M BaseT |
| Internal memory | MicroSD card up to 256GB |
| Remote access | Web Browser, Smartphone App Safire Smart, PC Software Safire Smart VMS |
| Interoperability | ONVIF |
| Power | DC 12 V / mA / 9 W max. / IEEE802.3af PoE |
| Degree of protection | Weatherproof IP67 |
| Material | Metallic |
| Temp. operation | -30º C ~ +60º C |
| Dimensions | 88.7 (H) x 100.2 (W) x 278.3 (D) mm |
| Weight | 1000 g |
