Brand | Hikvision | Model | DS-KM9503 |
Operating system | Android 7.1 RAM: 2 GB / ROM: 8 GB |
Screen type | 10.1" touch-sensitive color IPS |
Screen resolution | 1280 x 800 |
Operation mode | Touch buttons for answering calls, opening the door and using the speakerphone |
Inputs | 2 x configurable alarm inputs, 1 x RS485 , 3 x USB |
Outputs | 2 x relay outputs |
Audio | Omnidirectional audio with microphone and speakerphone with telephone (adjustable via software) Noise reduction and echo cancellation |
Memory | MicroSD card slot (up to 128 GB) |
Connection | 2 x Ethernet 10/100 BaseT / RTSP / SIP protocol 2.0 |
Remote access | Software iVMS-4200 |
Camera | 2 MP camera |
Capacity | Up to 128 IP cameras Up to 1000 SIP accesses |
Power | DC 12 V / 1 A max. / Standard PoE IEEE802.3af |
Temp. operation | -10º C ~ +50º C |
Dimensions | 292 (H) x 166 (W) x 31(Fo) mm |
Weight | 1285 g |
Installation | Tabletop or surface mounted on a wall |
