| Brand | X-Security |
| Image sensor | 1/2.8” STARVIS CMOS |
| Resolution | 1080P(1920x1080), 720P(1280x720), D1(704x576), CIF(352x288) |
| Compression | H.265+/H.265/H.264+/H.264 (video), G711a / G771u / PCM (audio) |
| Main Stream rate | 1080P (1~25 FPS) / 720P (1~50 FPS) |
| Extra Stream rate | D1 / CIF (1~25 FPS) |
| Bitrate | 448 Kbps ~ 8 Mbps |
| Lens | Varifocal 5.1 ~ 61.2 mm (Optical Zoom 12X) Auto Iris |
| Digital zoom | 16 X |
| Image improvements | WDR (120dB), Ultra DNR, HLC, BLC, ATW, AGC, Privacy Mask, Motion detection |
| Intelligent detection | Line crossing, intrusion, abandoned object, face detection |
| Minimum illumination | 0.005 Lux (colour) / 0.0005 Lux (B/N) |
| Day / Night | Removable mechanical ICR filter |
| Network interface | Ethernet 10/100 BaseT |
| Remote access | WEB interface, CMS software, mobile application and NVR |
| Memory | Slot for Micro SD card (Max 128 GB) |
| Pan/Tilt Range | Horizontal: 0°~360°, Vertical: |
| Manual speed | Horizontal: 0.1°~300° /s, Vertical: 0.1°~120° /s |
| Speed between Presets | Horizontal: 300° /s, Vertical: 200° /s |
| Preset positions | 300, 5 auto pattern, 8 auto tour, 5 auto scan |
| Communication | DH-SD, ONVIF Compatible |
| Alarms | 2 inputs / 1 relay NO/NC |
| Audio | 1 input (Line In) / 1 output (Line Out) |
| Power | AC 24 V / 1.5 A , PoE IEEE802.3at |
| Degree of protection | Weatherproof IP66, Anti-vandal IK10 |
| Temp. operation | -40º C ~ +60º C |
| Dimensions | 234 mm (H) x 186 (Ø) mm |
| Weight | 2300 g |
