| Brand |
Safire Smart |
| Range |
E1 with Artificial Intelligence |
| Image sensor |
1/2.8“ Progressive Scan CMOS |
| Resolution |
8 Megapixel (3840x2160) |
| Main Stream |
3840× 2160, 2560× 1440, 1920× 1080, 1280× 960, 1280× 720 |
| Sub stream |
704x576, 640x480, 352x288 |
| Third Stream |
1920×1080, 1280×960, 1280×720, 704×576, 640×480, 352×288 |
| Video Bit rate |
64Kbps ~ 16Mbps |
| Minimum illumination |
Colour: 0.01 Lux @(F1.2, AGC ON), 0 Lux with IR |
| IR LED |
200 m |
| Compression |
H.265+/H.265/H.264+/H.264 |
| Optical Zoom |
32X |
| Digital Zoom |
16X |
| Lens |
4.8 - 154 mm |
| FOV |
H: 61.3º - 2.18º / V: 36.9º - 1.22º / D: 68.4º - 2.5º |
| Range performance |
W: 138 m (D), 55 m (O), 28 m (R), 14 m (I)
T: 3528 m (D), 1400 m (O), 700 m (R), 350 m (I) |
| Electronic shutter |
1/1s~1/10,000s |
| Day / Night |
Removable mechanical ICR filter |
| Image improvements |
BLC, HLC, WDR, 3D-NR, AGC, AWB, MD, Privacy Masking, ROI |
| Advanced functions |
Artificial intelligence based on human-vehicle classification on: Area Intrusion, Line Crossing, Entry Region, Exit Region.
Face recognition with face capture of up to 15 faces at a time. |
| Intelligent Autotracking |
Intelligent tracking of humans and vehicles |
| Pan/Tilt Range |
Horizontal: 360°, Vertical: -5°~90° auto flip |
| Manual speed |
Horizontal: 0.5° ~ 120°/sec, Vertical: 0..5° ~120°/s |
| Speed between Presets |
Horizontal: 150° /s, Vertical: 150° /s |
| Preset positions |
360 Preset, 8 Tours, 4 Patrols |
| Internal memory |
MicroSD card, Max 256 GB |
| Audio |
1 Input / 1 Output |
| Audio Compression |
G.711 A/U |
| Audio bit rate |
64 Kbps |
| Alarms |
1 Input / 1 Relay |
| PTZ Control |
Through network access |
| Network interface |
Ethernet 10 / 100M BaseT |
| Remote access |
Web Browser, Smartphone App Safire Smart, PC Software Safire Smart VMS |
| Interoperability |
ONVIF, PSIA, CGI |
| Power |
DC 24 V , HiPoE (IEEE802.3bt) |
| Temp. operation |
-40º C ~ +65º C |
| Degree of protection |
IP66 / Surges 6000V |
| Dimensions (without bracket) |
317 mm (H) x 196(Ø) mm |
| Weight (without bracket) |
3700 g |
