| Brand | SAFIRE |
| Image sensor | 1/2.8" Progressive Scan CMOS |
| Maximum resolution | 4 Megapixel (2560x1440) |
| Minimum illumination | 0.005 Lux / B/W: 0.001 Lux |
| Main Stream rate | 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub-Stream Rate | 25 fps (704 × 576, 640 × 480, 352 × 288) |
| Third Stream Rate | 25 fps (704 × 576, 640 × 480, 352 × 288) |
| IR Distance | Range 20m |
| Compression | H.265+/ H.265 / H.264+/ H.264 |
| Lens | 2.8 - 12 mm Motorized |
| FOV | Horizontal: 96.7°~31.6°, Vertical: 51.1°~17.7°, Diagonal: 115.1°~36.3° |
| Digital zoom | 16X |
| Electronic shutter | 1/1s~1/30,000s |
| Manual Speed | Horizontal: 0-100°/s | Vertical: 0-100°/s |
| Day / Night | Removable mechanical ICR filter |
| Image improvements | BLC, HLC, 120dB WDR, 3D-NR, AGC, AWB, MD, Privacy Masking, ROI |
| Video analysis | VCA: Line crossing | Face detection | Area intrusion | Object removal detection | Abandoned object | Audio exception |
| Internal memory | MicroSD card, Max 256 GB |
| Audio | 1 input (Line In) / 1 output (Line Out) Microphone |
| Alarms | No |
| PTZ Control | Through network access |
| Network interface | Ethernet 10 / 100 BaseT WiFi IEEE802.11b, 802.11g, 802.11n, 2.4 GHz - 2.4835 GHz; Bandwidth 20/40 MHz |
| WiFi Encryption Mode | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Modulation | 802.11b: CCK, DQPSK, DBPSK, DBPSK 802.11g: OFDM/64-QAM, 16-QAM, QPSK, BPSK 802.11n: OFDM/64-QAM, 16-QAM, QPSK, BPSK |
| Remote access | Web browser, Safire Control Center Smartphone App and PC Software |
| Interoperability | ONVIF, PSIA, CGI |
| Power | DC 12 V / 12 W, PoE (802.3af) |
| Temp. operation | -20º C ~ +60º C |
| Degree of protection | Weatherproof IP66, Anti-vandal IK10 |
| Material | Aluminium alloy |
| Dimensions (without bracket) | 101.7 (H) x 130.7 (Ø) mm |
| Weight (without bracket) | 530 g |
