I/O Interface
|
|
|
Power
|
AC INPUT (100-240V)
|
|
Ethernet
|
4 Port 10/100/1000M PoE, 2 Port 1000M SFP
|
|
Performance
|
|
|
Bandwidth
|
12 Gbps
|
|
Throughput
|
8.928Mpps
|
|
Packet Buffer
|
1Mbit
|
|
MAC Address
|
2K
|
|
Transfer Mode
|
Store and forward
|
|
Standard
|
|
|
Network Protocol
|
IEEE802.3
IEEE802.3u
IEEE802.3ab
IEEE802.3z
IEEE802.3x
|
|
PoE Protocol
|
IEEE802.3af (15.4W)
IEEE802.3at (30W)
POE port output voltage: DC 52V
POE power supply core: 1/2+; 3/6
|
|
Industrial Standard
|
EMS: EN61000-4-2 (ESD)、 EN61000-4-5 (Surge
|
|
Network Medium
|
10BASE-T: Cat 3、4、5 UTP (≤100 meter)
100BASE-TX: Cat5 or more UTP (≤100 meter)
1000Base-TX: Cat5 or more UTP/STP (≤100 meter)
|
|
Function
|
|
|
LED Indicators
|
PWR (power supply), Mode (DIP), 1-6(Link & Data)
|
|
PWR
|
On: Powered on
Off: Powered off
|
|
POE LED Buttons
|
Dual color light selection: default green (link data), switch yellow light (POE)
|
|
DIP Switch
|
|
|
VLAN
|
Port isolation mode. In this mode, the PoE ports (1-4) of the switch cannot communicate with each other and can only communicate with the UP-link port.
|
|
Default
|
Normal mode, all port can communicate with each other, the transmission distance is within 100 meters, the transmission rate is 10M / 100/1000M adaptive;
|
|
Extend
|
Link extension mode, 3-4 ports PoE power supply and data transmission distance can be extended to 220 meters, the transmission rate becomes 10M
|
|
Environment
|
|
|
Working Environment
|
Working Temperature: -10~50°C
Storage Temperature: -40~70°C
Working Humidity:10%~90%, non-condensing
Storage Temperature:5%~95%, non-condensing
|
|
Physical Specifications
|
|
|
Dimension
|
Product Dimension: 200*118*44.5mm
Package Dimension: 245*190*60mm
N.W:0.67kg
G.W:0.97kg
|
|
Packing Info
|
Carton MEAS:520*320*400mm
Packing Qty:20 units
Packing Weight:20.4KG
|
|
Power Voltage
|
Input Voltage: AC 100-240 V
Power supply:52V /1.25A
|
|
Power
|
Product power: maximum 5W
POE power: maximum 60W
|
