| Brand | Uni-T |
| Measuring range DC and AC current | AC: 600A ±(2.5%+5); Response frequency: 50~100Hz DC: 600A ±(2.5%+5) |
| DC and AC voltage measuring range | AC: 600V ±(0.8%+5); Response frequency: 10Hz~60kHz DC: 600V ±(0.5%+2) |
| Resistance measuring range | 60MΩ ±(0.8%+2) |
| Capacitance measuring range | 60mF ±(4%+5) |
| Frequency measurement range | 10Hz~10MHz ±(0.1%+4) |
| Temperature measurement range | -40℃~1000℃ ±(1.5%+5) |
| Display accounts | Up to 6000 |
| Display dimensions | 37mm x 25mm |
| Clamp opening | 28mm |
| Auto Range / Manual Range / True RMS | Yes, it is available |
| Diode test | Yes, it is available |
| NCV function (non-contact voltage detection) | Yes, it is available |
| Relative mode | Yes, it is available |
| MAX/MIN register | Yes, it is available |
| Continuity test | Yes, it is available |
| Low battery indicator | Yes, it is available |
| Zero mode | Yes, it is available |
| Power | 2 x batteries (R03) 1.5V |
| Dimensions | 215 (H) x 63 (W) x 36 (D) mm |
| Weight | 235 g |
| Security | CAT III 300V/ CAT II 600V CAT II [%VAR%] |
