DS-KD8003Y-IME2 | |
| Brand | Hikvision |
| Model | DS-KD8003Y-IME2 |
| Operating system | Linux |
| Image sensor | Low Illumination 2 Mpx IR |
| Image Functions | BLC / WDR / DNR |
| Viewing angle | H: 146º, V: 82º, D: 180º |
| Audio | Bidirectional audio with microphone and speaker |
| Keypad | Mechanical button with LED backlit name-tag |
| Outputs | 2 x lock relay, 1 x module output, 1 x DC 12 V / 500 mA max. |
| Inputs | 4 x auxiliary inputs (output button, feedback, door sensor), 1 x tamper |
| Remote access | Software iVMS-4200 Hik-Connect mobile application |
| Network interface | Network connection through 2 threads / SIP protocol 2.0 |
| Modular | Compatible with Hikvision modular boards |
| Power | DC 24 V with hub 2 wires / 12 V / 1700 mA max. |
| Degree of protection | Suitable for exterior IP65 |
| Material | Plastic |
| Temp. operation | -40º C ~ +60º C |
| Dimensions | 98 (H) x 100 (W) x 42 (D) mm |
| Weight | 374 g |
DS-KH6320Y-WTE2 | |
| Brand | Hikvision |
| Model | DS-KH6320Y-WTE2 |
| Operating system | Linux |
| LCD | 7" color touch-screen TFT |
| Screen resolution | 1024 x 600 |
| Inputs | 8 x configurable alarm inputs, 1 x RS485 |
| Outputs | 2 x relay outputs |
| Audio | Two-way audio with integrated microphone and loudspeaker Noise reduction and echo cancellation |
| Memory | MicroSD card slot (up to 128 GB) |
| Connection | 2 wires / RTSP / SIP Protocol 2.0 / WiFi 802.11b/g/n (only for connection to app via P2P)) |
| Remote access | Software iVMS-4200 Hik-Connect mobile application |
| Power | Through specific Hikvision hub for video intercoms of 2 wires (6 W max) |
| Temp. operation | -10º C ~ +50º C |
| Dimensions | 140 (H) x 200 (W) x 15 (D) mm |
| Weight | 327 g |
| Slave monitors | It is not possible to use the Android DS-KH9310 and DS-KH9510 monitors as slaves |
DS-KAD704Y | |
| Brand | Hikvision |
| Model | DS-KAD704Y |
| Operation mode | Power, video and audio through 2 wire technology |
| Outputs | 4 channels of 2 wires |
| Cascade | 2 channels for cascade connection of DS-KAD706Y or DS-KAD706Y |
| Communication | 2 threads technology (up to 4 devices) |
| Network interface | Ethernet 10/100 BaseT |
| Power | DC 24 V / 2.5 A max. |
| Temp. operation | -10º C ~ +55º C |
| Weight | 250 g |
