Brand | SAFIRE | Video format | HDTVI / HDCVI / AHD / CVBS / IP |
Video inputs | 4 Channels BNC (HDTVI / HDCVI / AHD / CVBS) |
Hybrid configuration | Default: 4 Channels from BNC and 4 (substitution) + 1 (extra) IP Channels (up to 1080P) |
Video outputs | 1 HDMI, 1 VGA |
Audio inputs | 1 Channel RCA |
Audio outputs | 1 Channel RCA |
Bidirectional audio | Reusing first audio input |
Video / audio compression | H.264+ / H.264 / G.711u |
Display resolution | 1920x1080, 1280x1024, 1280x720, 1024x768 |
BNC input resolution | 1080p / 720p |
Main Stream coding | 1080p Lite / 720p / VGA / WD1 / 4CIF / CIF (25 FPS) |
Extra Stream coding | WD1 / 4CIF (12FPS) / CIF (25 FPS) |
Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
Alarms | No |
Video analysis | No |
Recording method | Manual, programmed, motion detection |
Backup | USB / Network |
Internal memory | 1 HDD SATA 3.5" of up to 6TB (not included) |
Communication | 2 x USB 2.0 (Mouse and backup) / RJ45 (Ethernet) |
Remote access | Web browser, Smartphone App and Safire Control Center CMS Software |
Power | DC 12 V / 1.5 A (Consumption without HDD ≤16 W) |
Dimensions | 45 (H) x 200 (W) x 200 (D) mm / 1 Kg |
Weight | 800 g (without HDD) |
