| Brand | SAFIRE |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs | 16 Channels BNC, (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid configuration | Default: 16 Channels from BNC and 16 (replacement) + 2 (extra) IP Channels (up to 6Mpx) Enhanced IP Mode: 16 Channels from BNC and 16 (replacement) + 8 (extra) IP Channels (up to 6Mpx) Enhanced IP mode limits bandwidth to 4Mbps per IP channel |
| Input bandwidth | 96 Mbps |
| Video outputs | 1 HDMI Full HD, 1 VGA, 1 BNC (CVBS) Independent * HDMI and VGA are simultaneous |
| Audio | 16 ch over Coaxial cable (HDTVI), 1 input / 1 RCA output |
| Bidirectional audio | Using Audio Inputs and RCA Output |
| Video / audio compression | H.265Pro+ / H.265Pro / H.264+ / H.264 / G.711u |
| Display resolution | HDMI: 1920x1080, 1280x1024, 1280x720, 1024x768 VGA: 1920x1080, 1280x1024, 1280x720, 1024x768 |
| BNC input resolution | 4Mpx / 1080p / 720p |
| Main Stream coding | 4 Mpx Lite / 1080P (15 FPS), 720p / VGA / WD1 / 4CIF / CIF (25 FPS) |
| Extra Stream coding | WD1 / 4CIF (12FPS) / CIF (25 FPS) |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Alarms IN / OUT | No |
| Advanced features | Facial recognition: Up to 1 analog channel for face comparison Truesense: Up to 4 channels (False alarm filter capable of classifying objects between humans and vehicles) Note: TrueSense and Facial Recognition cannot be enabled at the same time. |
| Recording method | Manual, programmed, motion detection, alarm |
| Backup | USB / Network/ Cloud (Microsoft One Drive, Dropbox) |
| Internal memory | 1 HDD SATA 3.5" of up to 10TB (not included) |
| Communication | RS485 (PTZ) / 2 x USB 2.0 (Mouse and backup) / 1xRJ45 10/100M (Ethernet) |
| Remote access | Web browser, Smartphone App and Safire Control Center CMS Software |
| Power | DC 12 V / 2 A (HDD Consumption < 18 W) |
| Dimensions / Weight | 45 (H) x 315 (W) x 242 (D) mm / 1.78 Kg |
