8 TB HARDDISK FOR OVERVÅKNING
kr 3,190.00
Brand | Safire Smart |
Video format | HDTVI / HDCVI / AHD / CVBS / IP |
Video inputs | 4 BNC channels (HDTVI / HDCVI / AHD / CVBS) |
Hybrid configuration | Default: 4 Channels from BNC and 4 (substitution) + 2 (extra) IP Channels (up to 8 Mpx) |
Video outputs | 1 HDMI 4K, 1 VGA |
Audio inputs | 4 RCA channels |
Audio outputs | 1 Channel RCA |
Bidirectional audio | Reusing the audio input/output |
Video / audio compression | H.265 / H.264 |
Display resolution | HDMI × 1 : 3840 × 2160 / 1920 × 1080 / 1280 × 1024 / 1024 × 768 VGA × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768 BNC × 1 : CVBS |
BNC input resolution | TVI/ AHD/CVI: 4K@15fps, 5MP@20fps, 4MP/3MP/1080P/720P/WD1@30fps |
Main Stream coding | 4K@6fps /7fps (PAL/NTSC) (only supported by the 1) channel) 4K Lite@12fps/15fps (PAL/NTSC) 5MP@12fps (PAL / NTSC) 5MP Lite@20fps (PAL / NTSC) 4MP/3MP@12fps / 15fps (PAL / NTSC) 4MPLite/1080P/720P/WD1/D1@25fps/ 30fps(PAL / NTSC) |
Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
Bit Rate | 32Kbps ~ 4Mbps |
Bandwidth | 16 Mbps (Incoming) / 40 Mbps (Outgoing) |
Alarms | 4 inputs / 1 relay |
Smart Features | Motion Detection VCA Rules: Line crossing and area intrusion |
Recording method | Manual, scheduled, smart events |
Backup | USB / Network |
Internal memory | 1 HDD SATA 3.5" of up to 10TB (not included) |
Communication | 2 x USB 2.0 (Mouse and backup) / RJ45 (Ethernet) / 1 x e-SATA |
Remote access | Web Browser, Safire Smartphone App and Safire Smart VMS software |
Power | DC 12 V / 2 A (Consumption without HDD < 10 W) |
Dimensions / Weight | 42 (H) x 300 (W) x 249 (D) mm / 1.2 Kg |
