| Brand | SAFIRE |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs | 16 Channels BNC, (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid configuration | Default: 16 Channels from BNC and 16 (replacement) + 8 (extra) IP Channels (up to 8Mpx) Enhanced IP Mode: 8 (extra) IP Channels (up to 8Mpx)) Enhanced IP mode limits bandwidth to 4Mbps per IP channel |
| Input bandwidth | 32 Kbps to 10 Mbps |
| Video outputs | 1 HDMI 4K, 1 VGA, 1 BNC (CVBS) Independent * HDMI and VGA are simultaneous |
| PoC power supply | Up to 8 PoC AT channels (12 W) + 8 PoC AF channels (6 W) or 8 PoC AT channels (12 W) |
| Audio | 4ch on Coaxial cable (HDTVI), 4 input / 1 output RCA |
| Bidirectional audio | Using Audio Inputs and RCA Output |
| Video / audio compression | H.265Pro+ / H.265Pro / H.264+ / H.264 / G.711u |
| Display resolution | HDMI: 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz VGA: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
| BNC input resolution | 8Mpx / 5Mpx / 4Mpx / 3Mpx / 1080p / 720p |
| Main Stream coding | 8 Mpx (8 FPS), 3K / 5Mpx (12 FPS), 4Mpx (15 FPS), 3Mpx (18FPS), 1080p / 720p / VGA / WD1 / 4CIF / CIF (25 FPS) * 8 Mpx (8FPS) only available on the channel 1 |
| Extra Stream coding | WD1 / 4CIF (12FPS) / CIF (25 FPS) |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Alarms IN / OUT | 8 / 4 |
| Advanced features | Facial recognition: Up to 1 analog channel for face comparison Truesense: Up to 4 channels (False alarm filter capable of classifying objects between humans and vehicles) Note: TrueSense and Facial Recognition cannot be enabled at the same time. |
| Recording method | Manual, programmed, motion detection, alarm |
| Backup | USB / Network / Cloud (Microsoft One Drive, Dropbox) |
| Internal memory | 2 HDD SATA 3.5" of up to 10TB (not included) |
| Communication | RS485 (PTZ) / 2 x USB 2.0 (Mouse and Backup) / RJ45 (Ethernet) |
| Remote access | Web browser, Smartphone App and Safire Control Center CMS Software |
| Power | DC 48 V / 2.5 A (Consumption without HDD < 15 W) |
| Dimensions / Weight | 48 (H) x 380 (W) x 320 (D) mm / 3.4 Kg |
