Brand | Hikvision | Range | PRO |
Inputs for IP cameras | LAN port up to 8 channels |
Power over Ethernet | Switch of 8 PoE IEEE802.3af/at ports [%VAR%] (max. 80 W) |
IP compatible cameras | HIKVISION (native protocol), ONVIF |
Bidirectional audio | 1 RCA output |
Video outputs | 1xHDMI 4K, 1xVGA simultaneous |
Video compression format | H.265+ / H.265 / H.264+ / H.264 |
Display resolution | HDMI: 4096x2160, 3840x2160, 2560x1440, 1920x1080, 1600x1200, 1280x1024, 1280x720 VGA: 1920x1080, 1280x1024, 1280x720 |
Total bandwidth | 80 Mbps downstream / 80 Mbps upstream |
Stream Type | Video / Video + Audio |
Main Stream recording | 8MP /6MP /5MP /4MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF |
Decoding capacity | 1CH@8MPx, 3CH@4MP, 6CH@1080p |
Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
Motion Detection | Motion detection 2.0 with human and vehicle classification applied in motion detection. Available up to 4 channels. * Motion detection and Acusense cannot be enabled at the same time on the same device. |
Alarms | No |
Recording method | Manual, programmed, motion detection |
External Backup | USB memory / HDD USB / CD-RW USB / DVR-RW USB |
Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
Remote connections | 32 |
Internal memory | 2 HDD SATA 3.5" of up to 8 TB each (not included) |
Communication | 2 x USB 2.0 / 1 x RJ45 10/100M (Ethernet) |
Power | DC 48 V / 2.5 A, ≤ 15 W (without HDD) |
Operating temperature | -10ºC ~ 55ºC (10%-90% Humidity) |
Dimensions / Weight | 52 (H) x 385 (W) x 315 (D) mm / 2.6 Kg (without HDD) |
