| Brand | Ruijie |
| Wireless standard | Wi-Fi 6 802.11ax |
| Frequencies | 2.4GHz & 5GHz |
| Wi-Fi performance | Up to 5375 Mbps Radio1: 2.4GHz - 574 Mbps Radio2: 5GHz - 4800 Mbps Up to 160MHz |
| Integrated antenna | 2.4GHz 5,9dBi, 5GHz 6,2dBi |
| Interfaces | 1 RJ45 5Gbps PoE In Port 1 SFP Port 5Gbps 1 Port RJ45 IoT with passive PoE Out 48v/12,95W 1 Console Port |
| SSID | Up to 32 |
| Operating modes | FIT: Adopted by Centralized AP Controller WS FAT: Standalone mode - Local Web Access Cloud: Managed through Ruijie Cloud |
| Security | WPA / WPA2 (AES) / WPA-PSK / WPA3 |
| Management | Web/Cloud/APP/Console |
| Concurrent Clients | Maximum Software: 1024 |
| Technologies | Hidden SSID Band Steering Load balancing based on number of users or traffic Bandwidth Control PPSK authentication (Proprietary) and 802.1X Rogue AP Detection Isolation between Wi-Fi clients CPU Protection Policy (CPP) Network Baseline Protection Policy (NFPP) Multicast to Unicast Conversion SNMP V1, V2c, V3< Bluetooth 5.1 |
| Compatible Hardware Controller | Series Controllers RG-WS6000 |
| Power | Jack connector 54Vdc/1,1A It is recommended to power the device with Hi-PoE 802.3bt If powered with PoE+ 802.3at the AP will work properly but will not be able to power other devices through the LAN2 IoT and USB ports If powered with PoE 802.3af the device will offer less performance in 2.4GHz and 5GHz |
| Operating temperature | -10 °C ~ 50 °C |
| Dimensions | 230 x 230 x 51 mm |
| Weight | 1,25 Kg |
